Product details of the froth pump
Product Description
CNSME PUMP froth pump is designed from a group of innovative engineers. We have implemented a rigorous quality control scheme. Quality assurance system is established to ensure the quality of froth pump.
Structure
The AF series froth pump has a simple structure, a high degree of universality, and is easy to install and use.
1.Transmission Part: The transmission part of this type of pump is the same as SP and SPR series slag slurry.The bearing housing is equipped with a motor seat or electrode frame, that is, direct transmission can be used, and the belt can be conveniently replaced to change the speed of the pump to meet the changes in working conditions.
2.Steel structure of vertical tank, and is equipped with a tangent entrance and an overflow nozzle. The overflow nozzle can conveniently send the excess incoming materials back to the tank. The tangent entrance can quickly enter the pump and eliminates some froth.
3.Pump Head: Double casings structure the pump head. Wet-end parts are metal lined, rubber lined or of other non-metallic material according to the different slurries.
SPECIFICATIONS
|
Model |
Power |
Capacity |
Head |
Speed |
Eff. |
Inlet dia. |
Outlet dia. |
|
P(KW) |
Q(m3/h) |
H(m) |
n(r/min) |
ŋ% |
(mm) |
(mm) |
|
|
2QV-AF |
3-15 |
6-43 |
6-30 |
800-1800 |
45 |
100 |
50 |
|
3QV-AF |
3-18.5 |
23-78 |
5-28 |
700-1500 |
55 |
150 |
75 |
|
4RV-AF |
5.5-37 |
33-187 |
5-28 |
500-1050 |
55 |
150 |
100 |
|
6SV-AF |
15-75 |
80-393 |
5-25 |
250-680 |
55 |
200 |
150 |
|
8SV-AF |
37-110 |
126-575 |
5-26 |
350-650 |
55 |
250 |
200 |
CONSTRUCTION OF 2QV-AF froth pump
Dimension Drawing
Application
Company Advantage
• Our company has established sales outlets throughout the country. Our products are exported to overseas regions, and are favored by consumers.
• CNSME PUMP has a high-quality management team, a professional management team, and a considerate service team. This provides a good guarantee for production, sales, and service.
• CNSME PUMP's location enjoys traffic convenience with multiple traffic lines passing through. This is conducive to the outward transportation and is the guarantee of timely supply of products.
CNSME PUMP's are of reliable quality and affordable price. If you have any interest in our products, feel free to call us.
Our professional slurry pump team is always At your services.
