Top Warman Pump Price List

Company Advantages

· CNSME PUMP warman pump is offered with the help of talented team of craftsmen.

· It is in high accordance with the first-class quality inspection standards.

· Shijiazhuang Minerals Equipment Co., Ltd. now serves many brand customers worldwide.

ADVANTAGE

High-efficiency conveying capacity

Equipped with 152mm outlet diameter and 203mm inlet diameter, it ensures high flow rate conveying and is suitable for high concentration of grit, slurry and other media.

Strong abrasion resistance

The sheath and impeller are made of metal with excellent abrasion resistance, suitable for conveying highly abrasive media and prolonging service life.

Large particle passing ability

With a maximum particle size of 127mm, it can easily handle media containing large particles and reduce the risk of clogging.

Closed impeller design

Close Type impeller, high efficiency and stable operation, suitable for conveying media containing solid particles.

Multiple sealing options

Three types of seals (e.g. mechanical seal, packing seal, etc.) can be selected flexibly according to the requirements of working conditions to ensure operational reliability and sealing effect.

High power support

Maximum power of 120kW, with a high speed of 1400rpm, to meet the needs of high-intensity operation.

Material Construction:

Description	Standard Material	Optional Material
Impeller	A05
Door	A05
Bowl	A05
Front Cover	A05
Back Liner	A05
Shaft	Carbon Steel	SUS304, SUS316(L)
Shaft Sleeve	3Cr13	SUS304, SUS316(L)
Shaft Seal	Gland Packing Seal	Expeller Seal, Mechanical Seal

SPECIFICATIONS

Pump        Model	S×D        (inch)	Allowable        Max. Power        (kw)	Clear Water Performance					Impeller
			Capacity Q	Head        H(m)	Speed        n(r/min)	Max.Eff.        η%	NPSH        (m)	No. of        Vanes	Vane Dia.        (mm)
			m3/h
SG/100D	6×4	60	36-250	5-52	600-1400	58	2.5-3.5	3	378
SG/150E	8×6	120	126-576	6-45	800-1400	60	3-4.5		391
SG/200F	10×8	260	216-936	8-52	500-1000	65	3-7.5		533
SG/250G	12×10	600	360-1440	10-60	400-850	65	1.5-4.5		667
SG/300G	14×12	600	432-3168	10-64	300-700	68	2-8		864
SG/400T	18×16	1200	720-3600	10-50	250-500	72	3-6		1067

Application

6-4DG

dredging pump

DSCN3768

sand gravel pump

Company Features

· Shijiazhuang Minerals Equipment Co., Ltd. is thought of an expert in producing warman pump. We also provide a series of related product portfolio.

· CNSME PUMP is a company who stresses the importance of warman pump quality.

· We work hard to understand the customer's schedule and needs. We strive to add value through the superior capabilities we manage and communicate in each project. Inquire!

Product Details

Adhering to the concept of 'details and quality make achievement', we will work harder on the following details of warman pump to make our products more advantageous.

Application of the Product

The warman pump developed by our company can play a role in various fields.

CNSME PUMP has been engaged in the production of for many years and has accumulated rich industry experience. Based on that, we could provide comprehensive and excellent solutions according to actual situations and the needs of different customers.
