Product details of the centrifugal pump suppliers

Product Information

The designers of CNSME PUMP centrifugal pump suppliers have earned years of experiences in the industry. Its functionality testing is in compliance with the expected standards. Shijiazhuang Minerals Equipment Co., Ltd.'s simple and efficient one-stop marketing service system can let customers trust us all the time.

Product Advantages

Highly efficient and Wear-resistant: industrial solutions for 12/10ST-AH slurry pumps 3 Adapt to submerged working conditions

Extended shaft design enables it to work deep into the liquid, suitable for deep pits, pools and tanks and other submerged environments, effectively solving the problem of conveying deep liquids, which cannot be handled by ordinary pumps.

Highly efficient and Wear-resistant: industrial solutions for 12/10ST-AH slurry pumps 3 Compact structure, space-saving

Vertical design covers a small area, suitable for installation in limited space, especially for mining, metallurgy, chemical industry and other occasions.

Highly efficient and Wear-resistant: industrial solutions for 12/10ST-AH slurry pumps 3 Stable operation, low vibration

Extended shaft design is calibrated by dynamic balance, low vibration and noise during operation, ensuring long-term stable operation of the equipment.

Highly efficient and Wear-resistant: industrial solutions for 12/10ST-AH slurry pumps 3 Easy installation and maintenance

Modular design makes installation and disassembly more convenient, and the extended shaft part can be maintained separately, reducing downtime and maintenance costs.

Highly efficient and Wear-resistant: industrial solutions for 12/10ST-AH slurry pumps 3 Strong adaptability

Capable of conveying medium with high concentration, high viscosity, strong corrosiveness or containing solid particles, widely used in mine tailings, metallurgical slurry, sewage treatment and other fields.

Specifications

Specifications of SP(R) Series Vertical Slurry Pumps
Model	Frame Type	Max. Rating (kW)	Sump Depthmm	Performance for Clear Water				Impeller
				Capacity Q	Head	Speed	Efficiency	Type	No. of Vanes	Vane Φmm	Passagemm
				m3/hr	m	r/min	%	Type	No. of Vanes	Vane Φmm	Passagemm
40PV-SP	PV	15	900	10--44	5--28	1000-2200	20-40	Open	5	188	12
40PV-SP	PV	15	900	10--40	9--37	1400-2600	15-32	Cyclo	8	195	26
40PV-SPR	PV	15	900	10--50	8--52	1200-3000	20-40	Open	5	188	12
65QV-SP	QV	30	1200	20--120	4--56	600-2000	25-51	Open	5	280	15
65QV-SP	QV	30	1200	20--110	5--28	700-1500	20-35	Cyclo	8	290	40
65QV-SPR	QV	30	1200	20--100	8--46	700-850	20-47.5	Open	5	280	23
100RV-SP	RV	75	1500	50--300	6--50	500-1400	20-56	Open	5	370	32
100RV-SP	RV	75	1500	50--250	6--31	600-1200	20-40	Cyclo	8	390	70
100RV-SPR	RV	75	1500	50--270	9--46	600-1400	30-60	Open	5	370	40
150SV-SP	SV	110	1800	100--500	7--37	500-1000	20-55	Open	5	450	45
150SV-SP	SV	110	1800	100--450	7--37	500-1000	20-40	Cyclo	8	480	80
150SV-SPR	SV	110	1800	100--450	7--35	500-1000	20-56	Open	5	450	45
200SV-SP	SV	110	1800	200--800	7--38	400-850	30-64	Open	5	520	65
250TV-SP	TV	200	1800	300--1000	8--35	400-750	20-63	Open	5	575	65
300TV	TV	200	2100	360--1400	5--28	350-700	20-62	Open	5	610	65
Material Options of Wet end Parts: A05, A33, A49, A61, R55

CONSTRUCTION OFSP(R) Series Vertical Slurry Pumps

Dimension Drawing

Specifications

Structure Characteristics

Vertical cantilever type, single pump casing structure: without any shaft seal, immersed in the liquid work, suitable for conveying abrasive, coarse particles, high concentration slurry. Wear resistant and corrosion resistant materials: the pump casing and impeller are made of wear-resistant and corrosion resistant materials, which can run for a long time under the harsh working environment.

三维图拷贝 2

外形图拷贝 2

pump used in slovakia (1) 拷贝

pump used in slovakia 拷贝

Application

Highly efficient and Wear-resistant: industrial solutions for 12/10ST-AH slurry pumps 3 Mining: Pumping slurry, improving the efficiency of ore processing

Highly efficient and Wear-resistant: industrial solutions for 12/10ST-AH slurry pumps 3 Metallurgy: Handling high concentration slurry, guaranteeing production continuity.

Highly efficient and Wear-resistant: industrial solutions for 12/10ST-AH slurry pumps 3 Coal: Conveying coal slurry in coal washing process, improving coal washing efficiency.

Highly efficient and Wear-resistant: industrial solutions for 12/10ST-AH slurry pumps 3 Chemical Industry: Conveying corrosive, coarse particles, high concentration slurry, to ensure production safety.

Company Advantage

• Our company attaches great importance to the talents cultivation. Therefore, we have created a talent team with rich industry experience in technology, management, sales and operation.
• CNSME PUMP owns a superior geographical location. There are traffic convenience, elegant ecological environment, and abundant natural resources.
• Our company's sales network has spread to many provinces, cities and autonomous regions in China. In addition, the products are also exported to Southeast Asia, Australia, North America and other countries and regions.
CNSME PUMP's are safe and practical with high cost performance. If you are interested in the products, you can contact us for consultation or call our hotline directly. We will serve you wholeheartedly.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
