Product details of the centrifugal pump company

Product Introduction

The well-designed centrifugal pump company makes it more special than other similar products. Statistical quality control technology is adopted in the production process to ensure the consistency of quality. The raw materials of CNSME PUMP centrifugal pump company are procured from recognized vendors.

More details

Highly efficient and Wear-resistant: industrial solutions for 12/10ST-AH slurry pumps 3 During use, the operating status of the pump, such as bearing temperature, sealing performance, etc., should be checked regularly to ensure the normal operation of the pump. At the same time, pay attention to observe the working noise and vibration of the pump. If there is any abnormality, it should be stopped for inspection immediately. For pumps that have been inactive or backup for a long time, they should be maintained regularly to extend their service life.

Highly efficient and Wear-resistant: industrial solutions for 12/10ST-AH slurry pumps 3 AF froth pump also needs to be operated safely during use. Before starting the pump, make sure that there is no leakage in the system to avoid accidents. During the operation of the pump, it is strictly forbidden to touch the rotating parts with your hands or other objects to avoid injury. At the same time, it is necessary to ensure that the pump’s inlet and export are unimpeded to prevent damage to the pump caused by blockage.

Specifications

Model	Power	Capacity	Head	Speed	Eff.	Inlet dia.	Outlet dia.
Model	P(KW)	Q(m3/h)	H(m)	n(r/min)	ŋ%	(mm)	(mm)
2QV-AF	3-15	6-43	6-30	800-1800	45	100	50
3QV-AF	3-18.5	23-78	5-28	700-1500	55	150	75
4RV-AF	5.5-37	33-187	5-28	500-1050	55	150	100
6SV-AF	15-75	80-393	5-25	250-680	55	200	150
8SV-AF	37-110	126-575	5-26	350-650	55	250	200

Structure OF 2QV-AF FROTH PUMP

1 (80)

2 (64)

CONSTRUCTION OF 2QV-AF froth pump

DIMENSION DRAWING

Application

Froth pump 拷贝 2

微信图片_20241212135346 拷贝

照片 003 拷贝
