Brand: CNSME
Model Number: SG/150E(Replacing the warman pump 8/6E-G)
Certificate: CE/ISO
Place of Origin: Hebei,China
Minimum Order Quantity: 1set
Delivery Time: 10-14 days
Payment Terms: T/T 100% deposit
Supply Ability: 500 sets per month
Packaging Details: Wooden crate
ADVANTAGE
High-efficiency conveying capacity
Equipped with 152mm outlet diameter and 203mm inlet diameter, it ensures high flow rate conveying and is suitable for high concentration of grit, slurry and other media.
Strong abrasion resistance
The sheath and impeller are made of metal with excellent abrasion resistance, suitable for conveying highly abrasive media and prolonging service life.
Large particle passing ability
With a maximum particle size of 127mm, it can easily handle media containing large particles and reduce the risk of clogging.
Closed impeller design
Close Type impeller, high efficiency and stable operation, suitable for conveying media containing solid particles.
Multiple sealing options
Three types of seals (e.g. mechanical seal, packing seal, etc.) can be selected flexibly according to the requirements of working conditions to ensure operational reliability and sealing effect.
High power support
Maximum power of 120kW, with a high speed of 1400rpm, to meet the needs of high-intensity operation.
재료 구성:
설명 | Standard Material | Optional Material |
Impeller | A05 | |
Door | A05 | |
Bowl | A05 | |
Front Cover | A05 | |
Back Liner | A05 | |
Shaft | Carbon Steel | SUS304, SUS316(L) |
Shaft Sleeve | 3cr13 | SUS304, SUS316(L) |
Shaft Seal | Gland Packing Seal | Expeller Seal, Mechanical Seal |
SPECIFICATIONS
Pump
모델 |
S×D
(inch) |
Allowable
최대. 힘 (kw) | Clear Water Performance | Impeller | |||||
Capacity Q |
Head
H(m) |
속도
n(r/min) |
Max.Eff.
η% |
NPSH
(m) |
아니요. of
Vanes |
Vane Dia.
(mm) | |||
m3/h | |||||||||
SG/100D | 6×4 | 60 | 36-250 | 5-52 | 600-1400 | 58 | 2.5-3.5 | 3 | 378 |
SG/150E | 8×6 | 120 | 126-576 | 6-45 | 800-1400 | 60 | 3-4.5 | 391 | |
SG/200F | 10×8 | 260 | 216-936 | 8-52 | 500-1000 | 65 | 3-7.5 | 533 | |
SG/250G | 12×10 | 600 | 360-1440 | 10-60 | 400-850 | 65 | 1.5-4.5 | 667 | |
SG/300G | 14×12 | 600 | 432-3168 | 10-64 | 300-700 | 68 | 2-8 | 864 | |
SG/400T | 18×16 | 1200 | 720-3600 | 10-50 | 250-500 | 72 | 3-6 | 1067 |
